CERN Dielectron Collision Data for Education

Education & Learning Analytics

Tags and Keywords

Dielectron

Cern

Physics

Collision

Events

Trusted By
Trusted by company1Trusted by company2Trusted by company3
CERN Dielectron Collision Data for Education Dataset on Opendatabay data marketplace

"No reviews yet"

Free

About

This dataset contains 100,000 particle collision events involving two electrons, specifically dielectron events. The data is provided within an invariant mass range of 2-110 GeV. It was specifically curated for outreach and education purposes and represents a subset of the total event information. It is important to note that the selection criteria used for this dataset may differ from those employed in official CMS physics results.

Columns

  • Run: The run number for each event. (Mean: 148,000, Std. Deviation: 920)
  • Event: The unique event number. (Mean: 496 million, Std. Deviation: 404 million)
  • E1: The total energy of electron 1, measured in GeV. (Mean: 36.4, Std. Deviation: 41.2)
  • px1: The first component (x) of electron 1's momentum, measured in GeV. (Mean: 0.14, Std. Deviation: 13.4)
  • py1: The second component (y) of electron 1's momentum, measured in GeV. (Mean: 0.18, Std. Deviation: 13.5)
  • pz1: The third component (z) of electron 1's momentum, measured in GeV. (Mean: -1.51, Std. Deviation: 51.6)
  • pt1: The transverse momentum of electron 1, measured in GeV. (Mean: 14.4, Std. Deviation: 12.4)
  • eta1: The pseudorapidity of electron 1. (Mean: -0.06, Std. Deviation: 1.46)
  • phi1: The phi angle of electron 1, measured in radians. (Mean: 0.02, Std. Deviation: 1.8)
  • Q1: The charge of electron 1. (Mean: -0.01, Std. Deviation: 1)
  • E2: The total energy of electron 2, measured in GeV. (Mean: 44, Std. Deviation: 46.8)
  • px2: The first component (x) of electron 2's momentum, measured in GeV. (Mean: 0, Std. Deviation: 13.1)
  • py2: The second component (y) of electron 2's momentum, measured in GeV. (Mean: 0.12, Std. Deviation: 13.2)
  • pz2: The third component (z) of electron 2's momentum, measured in GeV. (Mean: -1.59, Std. Deviation: 61.4)
  • pt2: The transverse momentum of electron 2, measured in GeV. (Mean: 13.8, Std. Deviation: 12.5)
  • eta2: The pseudorapidity of electron 2. (Mean: -0.07, Std. Deviation: 1.74)
  • phi2: The phi angle of electron 2, measured in radians. (Mean: 0.02, Std. Deviation: 1.82)
  • Q2: The charge of electron 2. (Mean: 0, Std. Deviation: 1)
  • M: The invariant mass of the two electrons, measured in GeV. (Mean: 30, Std. Deviation: 25.3)

Distribution

The dataset is provided in a CSV file named dielectron.csv. It contains 100,000 dielectron events, and consists of 19 columns. The file size is 14.74 MB. For the invariant mass (M), there are 99,900 valid entries. This dataset is not expected to be updated.

Usage

This dataset is ideal for educational purposes in physics and data science. It can be used for teaching and learning about particle collision analysis, invariant mass calculations, and fundamental concepts in high-energy physics. It is also suitable for data analytics exercises and scientific outreach programmes.

Coverage

The data consists of particle collision events recorded at CERN. The run numbers provided offer insight into the time range of data collection, such as runs from 146511.00 to 149182.00. This dataset originates from the CMS experiment at CERN and focuses on physics phenomena rather than having a traditional geographic or demographic scope.

License

CC0 Public Domain

Who Can Use It

  • Students studying particle physics or data analysis, for practical assignments.
  • Educators looking for real-world scientific data to enhance teaching materials.
  • Researchers for preliminary data exploration or to demonstrate concepts related to dielectron events.
  • Data analysts who wish to apply their skills to scientific datasets.

Dataset Name Suggestions

  • CERN Dielectron Collision Data for Education
  • High-Energy Physics Dielectron Events
  • CMS Electron Collision Data (Educational)
  • Particle Physics Dielectron Dataset
